Tophat Hinge V0

by MSiemons
Tophat Hinge V0
Simple hinge for V0 Tophat
2021-09-12T23:36:40
688
GPL v3.0
Hinge_panel_left_2.5mm.stl
Hinge_panel_left_2mm.stl
Hinge_panel_left_3mm.stl
Hinge_panel_right_2.5mm.stl
Hinge_panel_right_2mm.stl
Hinge_panel_right_3mm.stl
Images
Lower_Corner_adapted_1_and_3_Clip_x2.stl
Lower_Corner_adapted_2_and_4_Clip_x2.stl
STEPfiles
Hinge_panel_left.step
Hinge_panel_right.step
Tophat_Part_back_left.step
Tophat_Part_back_right.step
Tophat_Part_back_left.stl
Tophat_Part_back_right.stl
readme.md

I really like the design of the tophat of the V0 but wanted to be able to open and close it easily.

This is a hinge for the tophat of the V0, without changing the aesthetic. It uses modified panel mounts and tophat parts. I've added panels mounts for thicknesses of 2, 2.5 and 3mm. Also the lower corner clips are adapted to allow for the rotation. All parts can be printed without support.

Printed and tested: the tophat is relatively stable and stays in the open position.

Requirements:

4 x M3x20

6 x M3x12
